PHYSICAL SPECIFICATION |
||||||
|
|
||||||
|
Dimension |
Length |
173±2mm （6.81 inches） 111±2mm (4.37 inches) 329±2mm (12.95 inches) 365±2mm (14.37 inches) |
||||
|
Weight |
Approx. 13.5 Kg ±3% (29.75lbs) |
|||||
|
Standard Terminal |
Bolt-and-nuts terminal Bolt Type: M8 |
|||||
|
|
||||||
| ELECTRICAL SPECIFICATION | ||||||
|
Characteristics |
Discharge curves @ 25℃ (77 °F) |
|||||
|
Capacity |
20 hour rate (10.6A) 10 hour rate (20A) 5 hour rate (34A) 3 hour rate (50A) 1 hour rate (110A) |
212Ah 200Ah 170Ah 150Ah 110Ah |
 |
|||
|
Capacity affected |
40℃ （104 0F） 25℃ （77 0F） 0℃ （32 0F） |
102% 100% 85% |
||||
|
Max Discharge Current |
1000A (5 sec) | |||||
|
Short Circuit Current |
2600A | |||||
| Designed floating life | 15 years at 250C( 77 0F ) | |||||
|
Internal Resistance |
Full charged battery (25℃,77 0F) 0.75mΩ | |||||
|
Constant Voltage |
Cycle |
Initial Charging Current less than 50A Voltage 2.35~2.40V at 25℃ (77 0F ) Temperature Coefficient –5mV/℃ |
||||
|
Standby |
No limit on Initial Charging Current Voltage 2.23V at 25℃ (77 0F ) Temperature Coefficient –3.3mV/℃ |
|||||
|
CONSTANT CURRENT DISCHARGE RATING A@25℃ |
|||||||||
|
F.V/TIME |
15MIN |
30MIN |
1HR |
3HR |
4HR |
5HR |
8HR |
10HR |
20HR |
|
1.60V |
307.7 |
194.4 |
122.5 |
56.6 |
45.5 |
37.9 |
25.4 |
21.2 |
11.0 |
|
1.65V |
288.3 |
186.7 |
118.3 |
54.8 |
44.3 |
36.8 |
25.1 |
20.9 |
10.9 |
|
1.70V |
269.9 |
178.4 |
114.5 |
53.3 |
43.1 |
35.9 |
24.7 |
20.6 |
10.7 |
|
1.75V |
251.2 |
170.5 |
110.0 |
51.7 |
42.0 |
35.0 |
24.4 |
20.3 |
10.6 |
|
1.80V |
232.0 |
163.0 |
106.1 |
50.0 |
40.8 |
34.0 |
24.0 |
20.0 |
10.5 |
|
CONSTANT POWER DISCHARGE RATING WATT PER CELL@25℃ |
|||||||||
|
F.V/TIME |
15MIN |
30MIN |
1HR |
3HR |
4HR |
5HR |
8HR |
10HR |
20HR |
|
1.60V |
537.9 |
353.1 |
230.2 |
108.0 |
87.3 |
73.0 |
50.0 |
41.8 |
21.7 |
|
1.65V |
511.4 |
342.6 |
223.6 |
105.2 |
85.2 |
71.2 |
49.1 |
41.1 |
21.4 |
|
1.70V |
486.2 |
330.7 |
217.6 |
102.7 |
83.2 |
69.6 |
48.5 |
40.6 |
21.2 |
|
1.75V |
459.0 |
319.4 |
210.5 |
100.2 |
81.4 |
68.1 |
47.9 |
40.0 |
21.0 |
|
1.80V |
429.7 |
308.4 |
204.1 |
97.1 |
79.4 |
66.5 |
47.3 |
39.3 |
20.8 |
